Browse heavy-duty mecanum wheels, omni wheels and universal hubs for robotics, AGVs and industrial automation.
Need help selecting a wheel?Showing 1–16 of 143 results
-
-
Omni wheels (34)
-
Universal hubs (43)
-
100mm Mecanum Wheel Set MX100
The MX100 is a 100mm heavy-duty industrial mecanum wheel set rated for 100kg per set. Each wheel combines an aluminum alloy body with 8 aluminum-core polyurethane-coated rollers. The set is intended for AGVs, mobile robots, and industrial omnidirectional platforms that require controlled lateral, diagonal, and rotational movement. Specification: Diameter: 100mm (4 inches) Width: 54mm Number…
-
120mm Omni Wheel MU120
The MU120 is a 120mm heavy-duty industrial omni wheel rated for 70kg per wheel. Its steel body and 8 steel-core polyurethane-coated rollers support smooth lateral transfer and multidirectional movement in material-handling systems, AGVs, conveyors, and custom robotic platforms. Specifications: Diameter: 120mm Width: 64mm Number of rollers: 8 Number of plates: 2 Body material: Steel Roller…
-
127mm Mecanum Wheel Set MX127
The MX127 is a 127mm heavy-duty industrial mecanum wheel set rated for 200kg per set. Each wheel combines an aluminum alloy body with 8 aluminum-core polyurethane-coated rollers. The set is intended for AGVs, mobile robots, and industrial omnidirectional platforms that require controlled lateral, diagonal, and rotational movement. Specification: Diameter: 127mm (5 inches) Width: 66mm Number…
-
127mm Omni Wheel MU127
The MU127 is a 127mm heavy-duty industrial omni wheel rated for 100kg per wheel. Its steel body and 8 steel-core polyurethane-coated rollers support smooth lateral transfer and multidirectional movement in material-handling systems, AGVs, conveyors, and custom robotic platforms. Specifications: Diameter: 127mm (5 inches) Width: 90mm Number of rollers: 8 Number of plates: 2 Body material:…
-
152mm Mecanum Wheel Set MX152
The MX152 is a 152.4mm heavy-duty industrial mecanum wheel set rated for 300kg per set. Each wheel combines an aluminum alloy body with 8 aluminum-core polyurethane-coated rollers. The set is intended for AGVs, mobile robots, and industrial omnidirectional platforms that require controlled lateral, diagonal, and rotational movement. Specifications: Diameter: 152.4mm (6 inches) Width: 80mm Number…
-
152mm Omni Wheel MU152
The MU152 is a 152mm heavy-duty industrial omni wheel rated for 100kg per wheel. Its steel body and 8 steel-core polyurethane-coated rollers support smooth lateral transfer and multidirectional movement in material-handling systems, AGVs, conveyors, and custom robotic platforms. Specifications: Diameter: 152mm (6 inches) Width: 90mm Number of rollers: 8 Number of plates: 2 Body material:…
-
175mm Mecanum Wheel Set MX175
The MX175 is a 175mm heavy-duty industrial mecanum wheel set rated for 400kg per set. Each wheel combines an aluminum alloy body with 8 aluminum-core polyurethane-coated rollers. The set is intended for AGVs, mobile robots, and industrial omnidirectional platforms that require controlled lateral, diagonal, and rotational movement. Specifications: Diameter: 175mm Width: 94mm Number of rollers:…
-
203mm Mecanum Wheel Set MX203
The MX203 is a 203mm heavy-duty industrial mecanum wheel set rated for 600kg per set. Each wheel combines an aluminum alloy body with 8 aluminum-core polyurethane-coated rollers. The set is intended for AGVs, mobile robots, and industrial omnidirectional platforms that require controlled lateral, diagonal, and rotational movement. Specifications: Diameter: 203mm (8 inches) Width: 103mm Number…
-
203mm Omni Wheel MU203
The MU203 is a 203mm heavy-duty industrial omni wheel rated for 300kg per wheel. Its steel body and 8 steel-core polyurethane-coated rollers support smooth lateral transfer and multidirectional movement in material-handling systems, AGVs, conveyors, and custom robotic platforms. Specifications: Diameter: 203mm (8 inches) Width: 90mm Number of rollers: 8 Number of plates: 2 Body material:…
-
230mm Mecanum Wheel Set MX230
The MX230 is a 230mm heavy-duty industrial mecanum wheel set rated for 800kg per set. Each wheel combines an aluminum alloy body with 8 steel-core polyurethane-coated rollers. The set is intended for AGVs, mobile robots, and industrial omnidirectional platforms that require controlled lateral, diagonal, and rotational movement. Specifications: Diameter: 230mm (9 inches) Width: 113mm Number…
-
254mm Mecanum Wheel Set MX254
The MX254 is a 254mm heavy-duty industrial mecanum wheel set rated for 1500kg per set. Each wheel combines an aluminum alloy body with 8 steel-core polyurethane-coated rollers. The set is intended for AGVs, mobile robots, and industrial omnidirectional platforms that require controlled lateral, diagonal, and rotational movement. Specifications: Diameter: 254mm (10 inches) Width: 128mm Number…
-
254mm Omni Wheel MU254
The MU254 is a 254mm heavy-duty industrial omni wheel rated for 500kg per wheel. Its steel body and 8 steel-core polyurethane-coated rollers support smooth lateral transfer and multidirectional movement in material-handling systems, AGVs, conveyors, and custom robotic platforms. Specifications: Diameter: 254mm (10 inches) Width: 135mm Number of rollers: 8 Number of plates: 2 Body material:…
-
305mm Mecanum Wheel Set MX305
The MX305 is a 304.8mm heavy-duty industrial mecanum wheel set rated for 3000kg per set. Each wheel combines an aluminum alloy body with 8 steel-core polyurethane-coated rollers. The set is intended for AGVs, mobile robots, and industrial omnidirectional platforms that require controlled lateral, diagonal, and rotational movement. Diameter: 304.8mm (12 inches) Width: 156mm Number of…
-
305mm Mecanum Wheel Set MX305B
The MX305B is a 304.8mm heavy-duty industrial mecanum wheel set rated for 3000kg per set. Each wheel combines an aluminum alloy body with 9 steel-core polyurethane-coated rollers. The set is intended for AGVs, mobile robots, and industrial omnidirectional platforms that require controlled lateral, diagonal, and rotational movement. Diameter: 304.8mm (12 inches) Width: 140mm Number of…
-
350mm Omni Wheel MU350
The MU350 is a 350mm heavy-duty industrial omni wheel rated for 1200kg per wheel. Its steel body and 8 steel-core polyurethane-coated rollers support smooth lateral transfer and multidirectional movement in material-handling systems, AGVs, conveyors, and custom robotic platforms. Specifications: Diameter: 350mm Width: 193mm Number of rollers: 8 Number of plates: 2 Body material: Steel Roller…
-
355mm Mecanum Wheel Set MX355
The MX355 is a 355mm heavy-duty industrial mecanum wheel set rated for 4000kg per set. Each wheel combines an aluminum alloy body with 8 aluminum-core polyurethane-coated rollers. The set is intended for AGVs, mobile robots, and industrial omnidirectional platforms that require controlled lateral, diagonal, and rotational movement. Specification: Diameter: 355mm (14 inches) Width: 190mm Main…
