MM101 - 48mm Mecanum Wheel Set

Key specifications

Model: MM101
Diameter: 48mm
Width: 25.5mm
Load Capacity: 3kg
Body Material: Stainless Steel
Roller Material: TPR
Number of Rollers: 8

Inquire now

Send a product inquiry

Tell us about your requirements for MM101 - 48mm Mecanum Wheel Set.

SKU: MM101 Category: mecanum wheels

Description

Description

The MM101 - 48mm Mecanum Wheel Set is an industrial mecanum wheel for omnidirectional AGV, robotics and material-handling platforms. Contact MECAWHEEL to confirm load, hub, roller and mounting requirements.

The 48mm stainless steel mecanum wheel set includes two left wheels and two right wheels. Each wheel uses eight TPR rollers mounted at 45 degrees between two steel plates. Compatible 3mm, 4mm, and 5mm brass couplings are available for compact robotic platforms.

Specifications:
Diameter: 48mm
Width: 25.5mm
Number of rollers: 8
Number of plates: 2
Body material: Stainless Steel
Roller material: TPR
Length of roller: 25.5mm
Net weight: 56g x 4
Load capacity: 3kg

Compatible Hubs:

3mm MH135

https://www.mecawheel.com/product/3mm-brass-coupling-for-48mm-steel-mecanum-wheel-MH135
4mm MH136

https://www.mecawheel.com/product/4mm-brass-coupling-for-48mm-steel-mecanum-wheel-MH136
5mm MH137

https://www.mecawheel.com/product/5mm-brass-coupling-for-48mm-steel-mecanum-wheel-MH137
